[NEW]   HPH Series

Class I Division 2, Groups A, B, C and D, Class II Division 2 Groups F and G & Class III. NEMA-4X High-performance unit equipment for hazardous, damp and wet locations.

Specifications:
  • Class I, Div. 2, Groups A, B, C & D, Class II Div. 2, Groups F & G, Class III
  • Compact gray fiberglass housing with captive screws
  • NEMA-4X rated
  • All external fasteners and hardware are constructed of stainless steel
  • Simple and easy to install on walls, columns and struts
  • Column installation bracket sold separately (order catalog number: PMK1-E)
  • 1/2\" NPT conduit entry on top or side
  • High temperature lead-calcium battery operates 32°F to 122°F (0°C to 50°C) and nickel-cadmium battery operates 50°F to 104°F (10°C to 40°C) ; optional cold-weather -40°F to 122°F (-40°C to 50°C)
  • 15W high efficacy LED emergency heads outperform traditional 50W MR16-IR halogen
  • Innovative head design: four-LED and dual- driver provide illumination even in case of unexpected component failure
  • Infra-red remote control included in all models: allows testing the equipment without the need to climb a ladder. Distance range up to 30 ft. Universal, one remote control may test all the units on the job
  • Pulse plus charger
  • Low voltage disconnect
  • Automatic brownout protection
  • Battery lock-out
  • Fused output circuit
  • Standard Advanced Diagnostics
  • Optional NEXUS® monitoring system
  • 120/277 60Hz
  • UL 924 listed
  • Listed to the UL844 Standard for Class I, Division 2, Groups A, B, C & D, Class II, Division 2, Groups F & G and Class III
  • Unit has five-year limited warranty
